HT66F0175/HT66F0185
A/D Flash MCU with EEPROM
HT66F0175/HT66F0185
A/D Flash MCU with EEPROM
• ACERL Register
Bit 7 6 5 4 3 2 1 0
Name ACE7 ACE6 ACE5 ACE4 ACE3 ACE2 ACE1 ACE0
R/W R/W R/W R/W R/W R/W R/W R/W R/W
POR 1 1 1 1 1 1 1 1
Bit7 ACE7:DenePB3isA/Dinputornot
 0:NotA/Dinput
 1:A/Dinput,AN7
Bit6 ACE6:DenePA7isA/Dinputornot
 0:NotA/Dinput
 1:A/Dinput,AN6
Bit5 ACE5:DenePA6isA/Dinputornot
 0:NotA/Dinput
 1:A/Dinput,AN5
Bit4 ACE4:DenePA5isA/Dinputornot
 0:NotA/Dinput
 1:A/Dinput,AN4
Bit3 ACE3:DenePA4isA/Dinputornot
 0:NotA/Dinput
 1:A/Dinput,AN3
Bit2 ACE2:DenePB2isA/Dinputornot
 0:NotA/Dinput
 1:A/Dinput,AN2
Bit1 ACE1:DenePB1isA/Dinputornot
 0:NotA/Dinput
 1:A/Dinput,AN1
Bit0 ACE0:DenePB0isA/Dinputornot
 0:NotA/Dinput
 1:A/Dinput,AN0
