HT66F0175/HT66F0185
A/D Flash MCU with EEPROM
HT66F0175/HT66F0185
A/D Flash MCU with EEPROM
General Description
TheseriesofdevicesareFlashMemoryA/Dtype8-bithighperformanceRISCarchitecture
microcontroller.OfferinguserstheconvenienceofFlashMemorymulti-programmingfeatures,
thesedevicesalsoincludeawiderangeoffunctionsandfeatures.Othermemoryincludesanarea
ofRAMDataMemoryaswellasanareaoftrueEEPROMmemoryforstorageofnon-volatiledata
suchasserialnumbers,calibratuibdata,etc.
Analogfeaturesincludeamulti-channel12-bitA/Dconverterandacomparatorfunctions.Multiple
andextremelyflexibleTimerModulesprovidetiming,pulsegenerationandPWMgeneration
functions.ProtectivefeaturessuchasaninternalWatchdogTimer,LowVoltageResetandLow
VoltageDetectorcoupledwithexcellentnoiseimmunityandESDprotectionensurethatreliable
operationismaintainedinhostileelectricalenvironments.AfullchoiceofHXT,LXT,HIRCand
LIRCoscillatorfunctionsareprovidedincludingafullyintegratedsystemoscillatorwhichrequires
noexternalcomponentsforitsimplementation.Theabilitytooperateandswitchdynamically
betweenarangeofoperatingmodesusingdifferentclocksourcesgivesuserstheabilitytooptimise
microcontrolleroperationandminimizepowerconsumption.
TheinclusionofexibleI/Oprogrammingfeatures,Time-Basefunctionsalongwithmanyother
featuresensurethatthedeviceswillndexcellentuseinapplicationssuchaselectronicmetering,
environmentalmonitoring,handheldinstruments,householdappliances,electronicallycontrolled
tools,motordrivinginadditiontomanyothers.
Selection Table
Mostfeaturesarecommontoalldevices.ThemainfeaturesdistinguishingthemareMemory
capacity,I/Ocount,TimerModulefeatures,SSEGcount,LEDcount,UARTandpackagetypes.The
followingtablesummarisesthemainfeaturesofeachdevice.
Part No.
Program
Memory
Data
Memory
Data
EEPROM
I/O
External
Interrupt
A/D Timer Module
HT66F0175 2k × 16 128 × 8 64 × 8 22 2 12-bit × 8 10-bit PTM × 2
HT66F0185 4k × 16 256 × 8 128 × 8 26 2 12-bit × 8
16-bit CTM × 1
16-bit STM × 1
10-bit PTM × 1
Part No.
Time
Base
SIM UART CMP
SCOM/
SSEG
SSEG LED Stack Package
HT66F0175 2 √ — — 6 14 22 8 20/24SOP/SSOP
HT66F0185 2 √ √ √ 6 18 26 8 24/28SOP/SSOP
Note:Asdevicesexistinmorethanonepackageformat,thetablereectsthesituationforthepackagewith
themostpins.
