HT66F0175/HT66F0185
A/D Flash MCU with EEPROM
HT66F0175/HT66F0185
A/D Flash MCU with EEPROM
Register
Name
Bit
7 6 5 4 3 2 1 0
INTEG — — — — INT1S1 INT1S0 INT0S1 INT0S0
INTC0 — MF0F — INT0F MF0E — INT0E EMI
INTC1 TB0F ADF MF2F MF1F TB0E ADE MF2E MF1E
INTC2 — SIMF INT1F TB1F — SIME INT1E TB1E
MFI0 — — T0AF T0PF — — T0AE T0PE
MFI1 — — T1AF T1PF — — T1AE T1PE
MFI2 — — DEF LVF — — DEE LVE
Interrupt Registers List – HT66F0175
Register
Name
Bit
7 6 5 4 3 2 1 0
INTEG — — — — INT1S1 INT1S0 INT0S1 INT0S0
INTC0 — MF0F CPF INT0F MF0E CPE INT0E EMI
INTC1 TB0F ADF MF2F MF1F TB0E ADE MF2E MF1E
INTC2 URF SIMF INT1F TB1F URE SIME INT1E TB1E
MFI0 — — T0AF T0PF — — T0AE T0PE
MFI1 T2AF T2PF T1AF T1PF T2AE T2PE T1AE T1PE
MFI2 — — DEF LVF — — DEE LVE
Interrupt Registers List – HT66F0185
INTEG Register
Bit 7 6 5 4 3 2 1 0
Name — — — — INT1S1 INT1S0 INT0S1 INT0S0
R/W — — — — R/W R/W R/W R/W
POR — — — — 0 0 0 0
Bit7~4 Unimplemented,readas“0”
Bit3~2 INT1S1~INT1S0:InterruptedgecontrolforINT1pin
00:Disable
01:Risingedge
10:Fallingedge
11:Risingandfallingedges
Bit1~0 INT0S1~INT0S0:InterruptedgecontrolforINT0pin
00:Disable
01:Risingedge
10:Fallingedge
11:Risingandfallingedges
