HT66F0175/HT66F0185
A/D Flash MCU with EEPROM
HT66F0175/HT66F0185
A/D Flash MCU with EEPROM
INTC2 Register – HT66F0175
Bit 7 6 5 4 3 2 1 0
Name — SIMF INT1F TB1F — SIME INT1E TB1E
R/W — R/W R/W R/W — R/W R/W R/W
POR — 0 0 0 — 0 0 0
Bit7 Unimplemented,readas“0”
Bit6 SIMF:SIMinterruptrequestag
0:Norequest
1:Interruptrequest
Bit5 INT1F:INT1interruptrequestag
0:Norequest
1:Interruptrequest
Bit4 TB1F:TimeBase1interruptrequestag
0:Norequest
1:Interruptrequest
Bit3 Unimplemented,readas“0”
Bit2 SIME:SIMinterruptcontrol
0:Disable
1:Enable
Bit1 INT1E:INT1interruptcontrol
0:Disable
1:Enable
Bit0 TB1E:TimeBase1interruptcontrol
0:Disable
1:Enable
