Holtek HT66F0175 User Manual

Rev. 1.50 62 August 28, 2017 Rev. 1.50 63 August 28, 2017
HT66F0175/HT66F0185
A/D Flash MCU with EEPROM
HT66F0175/HT66F0185
A/D Flash MCU with EEPROM
Register
HT66F0175 HT66F0185
Reset
(Power On)
LVR Reset
(Normal Operation)
WDT Time-out
(Normal Operation)
WDT Time-out
(IDLE or SLEEP)*
SLCDC3 ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
SLCDC4 ● ---- --00 ---- --00 ---- --00 ---- --uu
SLEDC0 ● ● 0101 0101 0101 0101 0101 0101 uuuu uuuu
SLEDC1 ● --01 0101 --01 0101 --01 0101 --uu uuuu
SLEDC1 ● ---- 0101 ---- 0101 ---- 0101 ---- uuuu
IFS ● --00 0000 --00 0000 --00 0000 --uu uuuu
IFS ● -000 0000 -000 0000 -000 0000 -uuu uuuu
PD ● ---- 1111 ---- 1111 ---- 1111 ---- uuuu
PDC ● ---- 1111 ---- 1111 ---- 1111 ---- uuuu
PDPU ● ---- 0000 ---- 0000 ---- 0000 ---- uuuu
USR ● 0000 1011 0000 1011 0000 1011 uuuu uuuu
UCR1 ● 0000 00x0 0000 00x0 0000 00x0 uuuu uuuu
UCR2 ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
BRG ● xxxx xxxx xxxx xxxx xxxx xxxx uuuu uuuu
TXR_RXR ● xxxx xxxx xxxx xxxx xxxx xxxx uuuu uuuu
EEC ● ● ---- 0000 ---- 0000 ---- 0000 ---- uuuu
Note:“u”standsforunchanged
“x”standsfor“unknown”
“-“standsforunimplemented
