HT66F0175/HT66F0185
A/D Flash MCU with EEPROM
HT66F0175/HT66F0185
A/D Flash MCU with EEPROM
SLEDC1 Register – HT66F0175
Bit 7 6 5 4 3 2 1 0
Name — — — — PCPS3 PCPS2 PCPS1 PCPS0
R/W — — — — R/W R/W R/W R/W
POR — — — — 0 1 0 1
Bit7~4 Unimplemented,readas“0”
Bit3~2 PCPS3~PCPS2:PC6~PC4sourcecurrentselection
00:sourcecurrent=Level0(min.)
01:sourcecurrent=Level1
10:sourcecurrent=Level2
11:sourcecurrent=Level3(max.)
Bit1~0 PCPS1~PCPS0:PC3~PC0sourcecurrentselection
00:sourcecurrent=Level0(min.)
01:sourcecurrent=Level1
10:sourcecurrent=Level2
11:sourcecurrent=Level3(max.)
SLEDC1 Register – HT66F0185
Bit 7 6 5 4 3 2 1 0
Name — — PDPS1 PDPS0 PCPS3 PCPS2 PCPS1 PCPS0
R/W — — R/W R/W R/W R/W R/W R/W
POR — — 0 1 0 1 0 1
Bit7~6 Unimplemented,readas“0”
Bit5~4 PDPS1~PDPS0:PD3~PD0sourcecurrentselection
00:sourcecurrent=Level0(min.)
01:sourcecurrent=Level1
10:sourcecurrent=Level2
11:sourcecurrent=Level3(max.)
Bit3~2 PCPS3~PCPS2:PC6~PC4sourcecurrentselection
00:sourcecurrent=Level0(min.)
01:sourcecurrent=Level1
10:sourcecurrent=Level2
11:sourcecurrent=Level3(max.)
Bit1~0 PCPS1~PCPS0:PC3~PC0sourcecurrentselection
00:sourcecurrent=Level0(min.)
01:sourcecurrent=Level1
10:sourcecurrent=Level2
11:sourcecurrent=Level3(max.)
