Honeywell Home T10 - Page 10

33-00462—05 6
Fig. 6. Dimensions of J-Box adapter included with all T10
& T10+ models in inches (mm)
Fig. 7. Dimensions of molded grey cover plate included
with THX321WFS2001W in inches (mm)
Fig. 8. Dimensions of flat white cover plate included with
all T10 & 10+ models other than THX321WFS2001W in
inches (mm)
M37807
UP
329/32
(99)
329/32 (99)
M37808
513/64
(131)
51/2 (140)
13/32
(11)
11/16
(18)
9/32
(7)
67/64 (155)
67/64
(155)
M39055
