General| Type | Handheld bar code reader |
|---|---|
| Sensor type | CCD |
| Scanner type | 1D/2D |
| Read rate (max) | 270 reads/s |
| Maximum scan width | 610 mm |
| Pitch reading angle | -65 - 65 ° |
| Motion tolerance (cm/s) | 5 |
| Light levels (direct sunlight) | 0 - 70000 lx |
| Linear (1D) barcodes supported | CPC Binary, Codabar, Code 11, Code 128, Code 32, Code 39, Code 93, EAN-13, EAN-8, GS1-128 (UCC/EAN-128), ITF-14, JAN, MSI, Pharmacode, Plessey, Telepen, U.P.C. |
| 2D (matrix & stacked) barcodes supported | Codablock, Code 16K, Code 49, Composite Codes, Data Matrix, PDF417 |
| Battery life | 16 h |
| Charging time | 4 h |
| Input voltage | 12 V |
| Battery voltage | 3.7 V |
| Battery capacity | 1800 mAh |
| Power consumption | 852 mA |
| Power source type | Battery, DC |
| Number of reads per charge | 57000 |
| Power consumption (standby) | 1.2 W |
| Power consumption (typical) | 9.9 W |
| Number of batteries supported | 1 |
| USB version | 2.0 |
| PC connection | USB 2.0 |
| Wireless range | 10 m |
| Bluetooth version | 2.0+EDR |
| Connectivity technology | Wireless |
| Product color | Gray |
| Housing material | Plastic |
| Protection features | Dust resistant, Water resistant |
| Programming function | Yes |
| International Protection (IP) code | IP41 |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 0 - 95 % |
Weight and Dimensions| Depth | 165 mm |
|---|---|
| Width | 81 mm |
| Height | 157 mm |
| Weight | 261 g |
