Honeywell 3820 User Manual

vii
Korea Post Code....................................................... 6-32
Korea Post Message Length............................... 6-32
PosiCode A and B..................................................... 6-32
PosiCode Message Length ................................. 6-33
Trioptic Code............................................................. 6-33
Codablock F .............................................................. 6-34
Codablock F Message Length............................. 6-34
Code 16K .................................................................. 6-35
Code 16K Message Length................................. 6-35
Code 49..................................................................... 6-35
Code 49 Message Length ................................... 6-36
Chapter 7 - Interface Keys
Keyboard Function Relationships ............................... 7-1
Chapter 8 - Utilities
To Add a Test Code I.D. Prefix to All Symbologies..... 8-1
Reset Image Scanner ................................................. 8-1
Show Software Revision ............................................. 8-1
Show Data Format ...................................................... 8-1
Image Scanner Report ................................................ 8-2
Image Scanner Address.............................................. 8-2
Base Address.............................................................. 8-2
Resetting the Standard Product Default Settings:
Current Application Work Group............................... 8-2
Resetting the Standard Product Default Settings:
All Application Work Groups ....................................... 8-3
Temporary Visual Xpress Configuration ..................... 8-3
Chapter 9 - Visual Xpress
Visual Xpress Introduction .......................................... 9-1
Installing Visual Xpress from the Web................... 9-2
Chapter 10 - Serial Programming Commands
Conventions .............................................................. 10-1

Honeywell 3820 Specifications

General

Type	Handheld bar code reader
Sensor type	CCD
Scanner type	1D/2D
Read rate (max)	270 reads/s
Maximum scan width	610 mm
Pitch reading angle	-65 - 65 °
Motion tolerance (cm/s)	5
Light levels (direct sunlight)	0 - 70000 lx
Linear (1D) barcodes supported	CPC Binary, Codabar, Code 11, Code 128, Code 32, Code 39, Code 93, EAN-13, EAN-8, GS1-128 (UCC/EAN-128), ITF-14, JAN, MSI, Pharmacode, Plessey, Telepen, U.P.C.
2D (matrix & stacked) barcodes supported	Codablock, Code 16K, Code 49, Composite Codes, Data Matrix, PDF417
Battery life	16 h
Charging time	4 h
Input voltage	12 V
Battery voltage	3.7 V
Battery capacity	1800 mAh
Power consumption	852 mA
Power source type	Battery, DC
Number of reads per charge	57000
Power consumption (standby)	1.2 W
Power consumption (typical)	9.9 W
Number of batteries supported	1
USB version	2.0
PC connection	USB 2.0
Wireless range	10 m
Bluetooth version	2.0+EDR
Connectivity technology	Wireless
Product color	Gray
Housing material	Plastic
Protection features	Dust resistant, Water resistant
Programming function	Yes
International Protection (IP) code	IP41
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Depth	165 mm
Width	81 mm
Height	157 mm
Weight	261 g
