200 8680i User Guide
*Imaging Style - Photo SNPSTY1 156
Imaging Style - Manual SNPSTY2 156
Beeper On SNPBEP1 156
*Beeper Off SNPBEP0 156
*Wait for Trigger Off SNPTRG0 157
Wait for Trigger On SNPTRG1 157
*LED State - Off SNPLED0 157
LED State - On SNPLED1 157
Exposure (1-7874
microseconds)
SNPEXP 157
*Gain - None SNPGAN1 158
Gain - Medium SNPGAN2 158
Gain - Heavy SNPGAN4 158
Gain - Maximum SNPGAN8 158
Target White Value (0-255) *125 SNPWHT### 158
Delta for Acceptance (0-255) *25 SNPDEL### 158
Update Tries (0-10) *6 SNPTRY## 159
Target Set Point Percentage (1-
99) *50
SNPPCT## 159
Image Ship *Infinity Filter - Off IMGINF0 160
Infinity Filter - On IMGINF1 160
*Compensation Off IMGCOR0 160
Compensation On IMGCOR1 160
*Pixel Depth - 8 bits/pixel
(grayscale)
IMGBPP8 160
Pixel Depth - 1 bit/pixel (B&W) IMGBPP1 160
*Don’t Sharpen Edges IMGEDG0 161
Sharpen Edges (0-23) IMGEDG## 161
*File Format - JPEG IMGFMT6 162
File Format - KIM IMGFMT0 162
File Format - TIFF binary IMGFMT1 162
File Format - TIFF binary group 4,
compressed
IMGFMT2 162
File Format - TIFF grayscale IMGFMT3 162
File Format - Uncompressed
binary
IMGFMT4 162
File Format - Uncompressed
grayscale
IMGFMT5 162
File Format - BMP IMGFMT8 162
Selection
Setting
* Indicates default
Serial Command
# Indicates a numeric
entry
Page
