Honeywell AQ25A Series User Manual

AQ25400B “ADD-A-TEMPERATURE” EXPANSION CONTROL PANEL
19 69-1987—02
Installer Menu Structure
To display the Installer Menu, press and hold the OK button for
3 seconds. Fig. 9 illustrates all possible Installer Menu
selections.
Fig. 9. Installer Menu Structure.
M27813
ENTER
INSTALLER
MODE? NO
YES
INSTALLER MODE
INSTALLER MENU
1
THE  SYMBOLS INDICATE ADDITIONAL SELECTIONS ARE POSSIBLE.
THE FACTORY DEFAULT VALUES ARE SHOWN.
A VALUE OF “- -” INDICATES THE ITEM IS DISABLED OR NOT USED.
TEMPERATURE VALUES ARE SHOWN IN DEGREES FAHRENHEIT,
WHICH IS THE FACTORY DEFAULT TEMPERATURE UNIT.
VALVE OPEN TIME AND VALVE ACTION DISPLAY
ONLY IF MIX.VLV = ENABLE.
2
3
1
2
3
3
LOOP: B
MIXING 
PRI/SEC 
AUX 
SETUP 
TEST 
STATS 
-EXIT-
MIXING
MIX HIGH
TEMP: 140
MIX LOW
TEMP: 95
RESET: AUTO
DESIGN
TEMP: 120
10V MOD: DISABLE
INJECT.: ENABLE
MIX.VLV: DISABLE
VLV OPEN
TIME: 160
VALVE
ACTION: DIRECT
-EXIT-
PRI/SEC
ALL PRI
ALL SEC
B01: SEC
...
D16: SEC
-EXIT-
AUX
AUX: ZONE OPN
-EXIT-
SETUP
SAVE
RESTORE
FACTORY
-EXIT-
TEST
OUTPUTS:  - SEC PUMP / INJ PUMP / MIX VLV / 10V MOD / AUX / SEC PUMP / EXIT
SENSOR:  - SEC / EXIT
ZONES:  - SEC / ZONE B01 ... ZONE B16 / EXIT
PURGE:  - PURGE TIME / PURGE / START PURGE / PURGE OFF / EXIT
-EXIT-
STATS
LAST RST
100
AUX.PMP:
1,000H
SEC.PMP:
1,000H
INJ.PMP:
1,000H
MIX.VLV.
OP.CYCLE
1200
MIX.VLV.
CL.CYCLE
1200
RESET ?
ARE YOU SURE? NO
-EXIT-
