Calibration
Part No.: 44200004 - Revision 2 SVP Controller Operation Manual 4-11
Volumetric Water Draw Data Sheet
Date:
Prover Serial Number:
Prover Model Number:
Report Number:
Location:
Base Temperature (Tb):
Base Measure Volume-from calibration cert. (BMV):
Volume Measure Thermal Coefficient (Gc):
Compressibility Factor (water) (CPL):
Flow Tube Area Thermal Expansion Coefficient (Ga):
Detector Linear Thermal Expansion Coefficient (Gl):
Modulus of Elasticity of flow tube (E):
Flow Tube Inside Diameter (inches) (ID):
Flow Tube Wall Thickness (inches) (WT):
Fill 1 Fill 2 Fill 3 Fill 4 Fill 5
Fill Time (minutes) =
Flow Rate (Nominal Volume/Fill Time) =
Temperature Prover (Tp) =
Temperature Detector (Td) =
Prover Pressure (Pp) =
Scale Reading on Volume Measure (SR) =
Volume of Water adjusted for SR (BMVa) =
Test Measure Temperature (Ttm) =
Correction for Temp. Differential (Ctdw) =
Effect of Temp. on Test Measure (CTStm) =
Effect of Temperature on Prover (CTSp) =
Combined effect of CTSM & CTSP (CCTs) =
Volume Waterdraw (WD) =
Effect of Pressure on Flow Tube (CPSp) =
Compressibility of water in prover (CPLp) =
Corrected Water Drawn Volume (WDzb) =
Table 1: Volumetric Water Draw Data Sheet
