Honeywell 60 Series IP Camera Software Configuration Guide

detection or external alarm input devices. When an event is triggered, you can specify what

type of action that will be performed. You can configure the camera to send snapshots or

videos to your email address.

Figure 7-4 Event Settings

Event

In the Event tab, click ADD to open the event settings window. Here you can arrange three

elements -- Schedule, Trigger, and Action to set an event. A total of 3 event settings can be

configured.
