MC Toolkit Software with Honeywell HART Transmitters
Release 3 34-ST-25-20 MC Toolkit User Manual 39
9/06
Table 8 HART Displays / Tasks Summary
Menu Item Task
DEVICE INFO
Enter:
Device Type:
• Tag ID
• Message
• Descriptor
Observe (Read):
• Model
• Device ID
• Manufacturer
BASIC SETUP
Enter:
• LRV
• URV
Select:
• Damping
• PV Sensor Units (ST 3000,
STT25H, Generic
• PV1 & PV2 Units(STT25T)
• SV units (ST 3000)
• Transfer Function (ST 3000,
Generic)
• CJT Units (STT25H, STT25T)
• PV Units Type (Generic)
Observe
(Read):
• LRL
• URL
• Sensor Type (ST 3000)
OUTPUT
CONDITION
Select:
• Poll Adrs (0-15)
• Scaled D/A Trim (Output
Calibration procedure)
• NAMUR (STT 3000)
Observe
(Read):
• PV Output
• PV2 (STT25T)
• Alarm Direction
• Requested Preambles
ALARM (STT 3000)
Select:
• Break Detect (STT25H)
• Latching Alarm
• Clear Latching
• XS Delta Detection (STT25T
DIAGNOSTICS
/SERVICE
Select (Procedure):
• Master Reset
• Device Status
• Monitor (Output: mA, %; PV, PV2
[STT25T}, SV)
• Write Protect (Enter/Change
Password) (STT25H)
CALIBRATION
Select (Procedure):
Input Calibration
• Zero Trim (ST 3000 and Generic)
• Correct Input LRV (ST3000 and
STT25H)
• Correct Input URV (ST3000 and
STT25H)
• Reset Corrects (ST3000 and
STT25H)
Output Calibration
• Loop Test
• D/A Trim
Input (Re-Range to PV)
• Apply Values (LRV, URV)
To Next Page
