Honeywell MC ToolKit User Manual

Messages and Diagnostic Codes
Page 68 34-ST-25-20 MC Toolkit User Manual Release 3
9/06
Table 19 DE Messages
DE MESSAGES
Write NVM Failed Write to transmitter Non-Volatile Memory failed.
Unknown Device MC Toolkit does not support this transmitter.
Invalid Range User-entered value is too high or too low.
Invalid Request This transmitter does not support the command requested.
NACK MC Toolkit sensed Non-Acknowledgement of message to the
Transmitter.
Illegal Operation Typically caused by an invalid parameter or an attempt to perform an
operation in a mode not allowed by the transmitter.
Transmitter in Local Mode Transmitter in Factory Mode
Transmitter is Busy Transmitter was communicating when MC Toolkit sent message to
transmitter.
Invalid operation on Write Protected
Field
Attempt to write to a protected field.
Undefined Gross Status Byte from the
Transmitter
The transmitter has reported a status indication not understood by MC
Toolkit.
Gross Status Reserved Bit Set The transmitter has reported a status indication not understood by MC
Toolkit.
Data Inaccessible Unable to access the parameter value.
Bad character in Scratchpad The scratchpad contains an invalid data byte.
Invalid Float value Value is not a valid floating point value.
Value Out of Range User-entered number is too high or too low.
Transmitter is in DE Mode. D/A Trim is
allowed only in Analog Mode.
DE mode is digital only (no digital-to-analog conversion).
The transmitter is in Output Mode. Are
you sure you want to terminate the
connection?
User tried to Exit MC Toolkit application while the DE Transmitter is still
in Output Mode.
The changes you have made are about
to be sent to the transmitter. Continue?
Values entered into this display will be written into transmitter memory.
Please make sure you are connected to
a DE device. Sending DE commands to
a non-DE device could potentially cause
a process upset.
DE communications (~ 4-20 mA amplitude) could cause erroneous
transmission in non-DE protocols.
Leaving the Main Menu will require an
upload in order to return. Are you sure
you want to do this?
A new Upload will require approximately 60-second wait.
Put loop in Manual ... Trips secured? Changing values of transmitter parameters can cause process upset.
Conformity must be square root to
select this unit.
Units for Flow indications are available only when Square Root
conformity is selected.
