Honeywell MC ToolKit User Manual

Reference Data
Release 3 34-ST-25-20 MC Toolkit User Manual 77
9/06
Honeywell DE Fields and Values
Table 26 DE Fields and Values
Dialog Field Value
Device Info Tag ID Tag id (8 chars.)
Type Transmitter type
Firmware version Firmware version of the transmitter
Serial number Serial number of transmitter
Scratch pad 32 chars.
General PV Type
Dual Range
(STDC)
Single Range
Single Range
w/SV
Communication mode Analog DE 4 byte DE 6 byte
Failsafe Direction Upscale Downscale
Line Filter (STT only) 50 Hz 60 Hz
T/C Fault Detect (STT only) Enabled Disabled
DE Configure LRL, URL, LRV, URV Floating point
PV Units (STT only) °C
°F
K °R
PV Units (ST only) InH2O @ 39F
InH2O @ 68F
MmHg @ 0C
Psi
KPa
MPa
mBar
bar
g/cm²
kg/cm²
inHg @ 32F
mmH2O @ 4C
mH2O @ 4C
ATM
InH2O @ 60F
SV Units °C °F
Sensor Type (STT only) T/C J
T/C K
T/C T
T/C S
T/C R
T/C E
T/C B
T/C N
RTD-PT100J
Millivolts
RTD-PT100D
RTD-PT200
RTD-PT500
RTD-Ni500
RTD-Cu10
RTD-Cu25
T/C–RH
Radiamatic
T/C–W5W26
T/C–W3W25
Ohms
T/C-NiNiMo
Sensor Type (ST only) DP AP GP
Damping (STT only) 0.00
0.30
0.70
1.50
3.10
6.30
12.70
25.50
51.10
102.30
DE Configure
(continued)
Damping (ST only) 0.00
0.16
0.32
0.48
1.00
2.00
4.00
8.00
16.0
32.0
