Reference Data
Release 3 34-ST-25-20 MC Toolkit User Manual 89
9/06
XML Database (Samples)
XML database files that can be exported from the MC Toolkit application to Documint (or other XML file
utility) includes thirteen items. The specific content of each file depends on the type of field device from which
it is exported, but the form of each item is the same for all devices.
Example:
<Field name="Bus Type">HART</Field>
<Field name="
Parameter Name">Parameter Value</Field>
Two samples of XML files are given below - one for a Honeywell STT 3000 Smart Temperature Transmitter,
and the other for a non-Honeywell (or "generic") device by Smar.
An explanation of the parameters/values for each XML item is given in the table that follows the samples.
XML Sample - Honeywell DE
*******************************************************
<Record>
<Field name="Bus Type">DE</Field>
<Field name="Device">STT 3000</Field>
<Field name="Tag ID">XXXXXXXX</Field>
<Field name="Serial Number">B125340037</Field>
<Field name="Manufacturer">Honeywell</Field>
<Field name="Model Number">1.5</Field>
<Field name="Transfer Function">1</Field>
<Field name="Input Range : In Low">-20.0</Field>
<Field name="Input Range : In High">107.5</Field>
<Field name="Input Range : In Units">0</Field>
<Field name="Output Range : Out Low">4.00</Field>
<Field name="Output Range : Out High">20.00</Field>
<Field name="Output Range : Out Units">mA</Field>
</Record>
XML Sample - non-Honeywell HART
*********************************************************
<Database>
<Table name="Instrument">
<Record>
<Field name="Bus Type">HART</Field>
<Field name="Device">Generic</Field>
<Field name="Tag ID">SMAR</Field>
<Field name="Serial Number">816923</Field>
<Field name="Manufacturer">62</Field>
<Field name="Model Number">12345</Field>
<Field name="Transfer Function">0</Field>
<Field name="Input Range : In Low">-10.0</Field>
<Field name="Input Range : In High">100.0</Field>
<Field name="Input Range : In Units">39</Field>
<Field name="Output Range : Out Low">1.00</Field>
<Field name="Output Range : Out High">5.00</Field>
<Field name="Output Range : Out Units">58</Field>
</Record>
*******************************************************
