Messages and Diagnostic Codes
Release 3 34-ST-25-20 MC Toolkit User Manual 71
9/06
Table 21 ST 3000 Device Status Messages (DE)
ST3000 DEVICE STATUS MESSAGES (DE)
Meter Body Fault
Characterization PROM Fault or bad checksum
SUSPECT INPUT: The input process data seems wrong
Electronics Fault(A). MDU/DAC Compensation Fault
Electronics Fault(B)-RAM Fault
Electronics Fault(C)-NVM Fault
Electronics Fault(D)-NVM Fault
CRITICAL
Electronics Fault(E)-NVM Fault
Meter Body Sensor Over Temperature(>125C)
ZERO correction value is outside the acceptable limits for accurate operation
SPAN correction value is outside the acceptable limits for accurate operation
Transmitter is in the OUTPUT mode and is using a fixed output that is "not from the
process"
Meter Body Overload
Meter Body Fault: The pressure input is greater than two times the URL of the
transmitter
Calibration correction values are Reset to Factory default
NON CRITICAL
Data for the DAC Temperature compensation is corrupted
