Honeywell MC ToolKit User Manual

Reference Data
Release 3 34-ST-25-20 MC Toolkit User Manual 79
9/06
Honeywell HART Fields and Values
Table 27 HART Fields and Values
Dialog Field Value
Device Info Tag ID 8 chars
Model Transmitter type
Device ID Transmitter’s device ID
Manufacturer String
Message 32 chars
Descriptor 16 chars
Extended Info Universal Rev. Numerical
Software Rev. Numerical
Field Device Rev. Numerical
Poll Address Numerical
# Req. Preams Numerical
PV Sensor S/N Numerical
Final Assembly # Numerical
PROM ID Numerical
Basic Setup LRL, URL, LRV, URV Floating point
PV Sensor Units (ST
only)
InH2O @ 68F
InHg @ 0C
FtH2O @ 68F
MmH2O @ 68F
MmHg @ 0C
Psi
Bar
Mbar
g/cm²
kg/cm²
pascals
kPa
Torr
ATM
InH2O @ 60F
MPa
InH2O @ 4C
MmH2O @ 4C
PV Sensor Units
(STT only)
°C
°F
°R
Kelvin
MV
Ohms
Sensor Type (ST only) DP AP GP
SV Units °C
°F
°R Kelvin
Transfer Function Linear Square root
Damping (ST only) 0.00
0.16
0.32
0.48
1.00
2.00
4.00
8.00
16.0
32.0
Damping (STT only) Floating point between 0 and 100
