Generic HART Fields and Values
82 34-ST-25-20 MC Toolkit User Manual Release 3
9/06
Generic HART Fields and Values
Table 28 Generic HART Fields and Values
Dialog Field Value
Device Info Tag ID 8 chars
Model Transmitter type
Device ID Transmitter’s device ID
Manufacturer String
Message 32 chars
Descriptor 16 chars
Extended Info Universal Rev. Numerical
Software Rev. Numerical
Field Device Rev. Numerical
Hardware Revision Numerical
# Req. Preams Numerical
PV Sensor S/N Numerical
Final Assembly # Numerical
Physical Signaling Code Numerical
Basic Setup LRL, URL, LRV, URV Floating point
Minimum Span Floating point
Damping Floating point
PV Units Type
Temperature
Pressure
Volumetric flow
Velocity
Volume
Length
Time
Mass
Mass flow
Mass per volume
Viscosity
Electromagnetic
unit of electric
potential
Electrostatic unit of
current
Electromagnetic
unit of resistance
Energy
Power
Radial velocity
Miscellaneous
Generic
PV Sensor Units
Temperature
degC
degF
degR Kelvin
Pressure
inH2O @ 39F
inHg @ 32F
ftH2O @ 68F
mmH2O @ 68F
mmHg @ 0C
psi
bar
Mbar
g/cm²
kg/cm²
Pascals
KPa
torr
ATM
inH2O @ 60F
MPa
inH2O @ 4C
mmH2O @ 4C
