Messages and Diagnostic Codes
Release 3 34-ST-25-20 MC Toolkit User Manual 73
9/06
Table 23 ST 3000 Device Status Messages (HART)
ST3000 DEVICE STATUS MESSAGES (HART)
Invalid Database
PROM Failure
Suspect Input
DAC Diode Fault
NVM Fault
RAM Fault
PROM Fault
CRITICAL
PAC Fault
Sensor Over-temperature
Excess Zero Correction
Excess Span Correction
In Output Mode
M.B. Overload
Meter Body Fault
Corrects Reset
No DAC Temp. Compensation
Primary variable out of limits
Non primary variable out of limits
Loop current saturated - Analog output 1 and its digital representation are outside the
operating limits of the field device.
Loop current fixed - Analog output 1 and its digital representation are in fixed mode and
are not responding to input changes.
Cold Start A reset or self test of the device has occurred, or power has been removed or
applied.
Configuration changed
NON CRITICAL
Device Malfunction - Field device has malfunctioned due to a hardware error or failure.
