Reference Data
Release 3 34-ST-25-20 MC Toolkit User Manual 81
9/06
Dialog Field Value
Sensor Type (STT25T
only)
T/C-J
T/C-K
T/C-T
T/C-E
PT100 (RTD)
Line Filter 50 Hz 60 Hz
RTD Wire (STD25H) 3 Wire 4 Wire Sensor (STT only)
(continued)
CJ Mode Compensation
(STT25H)
Compensation
(STT25T)
Internal CJ External CJ
Write Protect (STT25H
only)
Write Protect Write protected
Not write
protected
Password 4 chars
New Password 4 chars
