Honeywell MC ToolKit User Manual

Honeywell HART Fields and Values
80 34-ST-25-20 MC Toolkit User Manual Release 3
9/06
Dialog Field Value
PV Output Floating point
PV2 (STT25T only)
Alarm Direction High Low
NAMUR (STT only) Enabled Disabled
Poll Address 0 - 15
Output Condition
Req. Preambles Numerical
Device Status Critical String
Non-Critical String
Info (STT25H only) String
Monitor Output (ma) Output current (floating point)
Output (%) Output percent (floating point)
PV
Primary variable output in engineering units (floating
point)
PV2 (STT25T only)
Primary variable 2 output in engineering units (floating
point)
SV Secondary variable in engineering units (floating point)
Local Meter (ST only) Meter Hardware Meter Installed
No Meter
Installed
Meter Units % of Span
inH2O @ 4C
mmHg @ 0C
psi
kPa
mPa
mBar
bar
g/cm²
kg/cm²
mmH2O @ 4C
inHg @ 0C
mH2O @ 4C
gal/min
gal/hr
Custom
Custom Units 8 chars
Flow EU High Floating point
Flow EU Low Floating point
Break Detect (STT25H
only)
Enabled
Disabled
Latching Alarm Enabled
Disabled
Alarm (STT only)
XS Delta On
Off
Sensor (STT only)
Sensor Type (STT25H
only)
MV
T/C-E
T/C-J
T/C-K
T/C-N
T/C-T
T/C-S
T/C-R
T/C-B
JPT 100
PT100
PT200
Ohms
