XML Database (Samples)
90 34-ST-25-20 MC Toolkit User Manual Release 3
9/06
Field # Parameter Name Parameter Description
1
Bus Type
Protocol type
2
Device
Classification of device type: Honeywell DE (ST 3000,
STT3000, Honeywell HART (STT25H), or generic (non-
Honeywell) HART
3
Tag ID
User-defined identifier
4
Serial Number
Serial Number of device (assigned by Manufacturer)
5
Manufacturer
a. Name of Manufacturer (Honeywell)
b. Numeric Code for Manufacturer's Name
6
Model Number
a. Firmware Version (Honeywell DE Transmitter)
b. Final assembly number (Honeywell HART and generic
HART)
7
Transfer Function
Code for output form (0= Linear; 1= Square Root)
8
Input Range : In Low
LRV
9
Input Range : In High
URV
10
Input Range : In Units
Code for Engineering Units (PV Input)
11
Output Range : Out Low
Output Range 0 % value (1 V or 4 mA)
12
Output Range : Out High
Output Range 100 % value (5 V or 20 mA)
13
Output Range : Out Units
a. mA or Volts (Honeywell DE)
b. Numeric Code for Engineering Units (HART)
