126
www.honeywell.com
Page 126
Mini-AT User Guide
Default = 0.00
Item
No. Item Name Description
————————————————————————————————————————
258 SLTBLE REP ITEM 1 The first of four user selectable Audit Trail Report Items that can be
configured for Audit Trail memory. To use these four items, insert the
desired item code number into any of the report locations (258 - 261).
The value “255” at any of theseReport Items will cause that position
to be ‘blank’. The Audit Trail logger can be configured to record four
or
ten item values in each audit trail record. See Item Codes 229 - 234
for further information.
Default: 225 (Incrv CorVol)
259 SLTBLE REP ITEM 2 See above. Default: 226 (Incrv UnVol)
260 SLTBLE REP ITEM 3 See above. Default: 206 (Avg. PCor Gas Pressure)
261 SLTBLE REP ITEM 4 See above. Default: 207 (Avg. Temperature)
262 DATE FORMAT Code (0 - 2) to select the format in which the Date is entered and
displayed at item 204. The format for all date related items (213,
244, 247, etc.) will also be governed by the selection of item 262.
Select: 0 - MM:DD:YY-----Default
1 - DD:MM:YY
2 - YY:MM:DD
263 AT TIMELOG TIMESTAMP Selection to determine how Audit Trail data is downloaded from
the instrument. Selecting ‘0’ will download audit trail records the
same as in the past. (i.e. when a snapshot of the Audit Trail item
values were taken.) Selecting ‘1’ will shift interval based values
(ex. Item 225 Incremental Corrected Volume) into the previous
time log (i.e. start of the interval). Absolute values (ex. Item
000 Corrected Volume) will remain in their original time log (i.e.
end of the interval). This feature was added to allow incremental
Audit Trail data (consumption) to be displayed at the time interval
of its usage.
Select: 0 - End of Interval Default
1 - Start of Interval
268 JUMPER SETTINGS The Mini-AT incorporates jumpers on the main circuit board as
another means of configuring some modes of operation. Since the
jumpers are physical entities, they cannot be changed via software.
Item 268 provides a means of reporting which jumpers are installed
at JB24. Normally (i.e. default), the only jumper installed at JB24
is across pins 5 & 6. Other jumper may be installed if those
