Mini-AT User Guide
Table 7
Form C Pulse Output Scaling
Selected
Volume Units
Item 90, 91 & 92
Units
CuFt
CuFt
X
10
CuFt
X
100
CuFt
X
1000
CuFt
X
10,000
m3
X
0.1
m3
X
1
m3
X
10
m3
X
100
m3
X
1000
CuFt
1.00000 0.10000 0.01000 0.00100 0.00010 0.28317 0.02831 ----- ----- -----
CuFt x 10
10.00000 1.00000 0.10000 0.01000 0.00100 2.83170 0.28317 0.02831 ----- -----
CuFt x 100
(CCF) ----- 10.00000 1.00000 0.10000 0.01000 28.31700 2.83170 0.28317 0.02831 -----
CuFt x 1,000
(MCF) ----- ----- 10.00000 1.00000 0.10000 ----- 28.31700 2.83170 0.28317 0.02831
CuFt x 10,000
----- ----- ----- 10.00000 1.00000 ----- ----- 28.31700 2.83170 0.28317
m3 x 0.1
3.53140 0.35314 0.03531 ----- ----- 1.00000 0.10000 0.01000 0.00100 0.00010
m3 x 1.0
35.31400 3.53140 0.35314 0.03531 ----- 10.00000 1.00000 0.10000 0.01000 0.00100
m3 x 10
----- 35.31400 3.53140 0.35314 0.03531 ----- 10.00000 1.00000 0.10000 0.01000
m3 x 100
----- ----- 35.31400 3.53140 0.35314 ----- ----- 10.00000 1.00000 0.10000
m3 x 1,000
----- ----- ----- 35.31400 3.53140 ----- ----- ----- 10.00000 1.00000
Pulse Output Scaling Factor
(Item 56 & 57)
Form-C type output
Desired Pulse Output Value
Form-C Configuration Examples:
To configure the Mini-AT that is programmed for corrected volume in MCF (1000 CuFt) to output an
MCF corrected volume pulses via the single* form C channel, configure the following items:
Item # Description Value
090 Corrected Volume Units MCF
056 Pulser A Scaling 1.0000
093 Pulser A Volume Code CorVol
094 Pulser B Volume Code No Out
115 Output Pulse Code 0.0625
To configure the Mini-AT
that is programmed for corrected volume in CCF (100 CuFt) to output a CCF
corrected volume pulses via the single* form C channel, configure the following items:
Item # Description Value
090 Corrected Volume Units CCF
056 Pulser A Scaling 1.0000
093 Pulser A Volume Code CorVol
094 Pulser B Volume Code No Out
115 Output Pulse Code 0.0625
*Note: Only one form C channel is available.
