54
www.honeywell.com
Page 54
Mini-AT User Guide
Item Item Legend Selected Description
Code# Item
075 Mag List 2 Item 1 # 200 Site ID
076 Mag List 2 Item 2 # 113 High Resolution CorVol
077 Mag List 2 Item 3 # 013 Base Pressure
078 Mag List 2 Item 4 # 014 Atmospheric Pressure
079 Mag List 2 Item 5 # 025 Transducer Range
080 Mag List 2 Item 6 # 044 Pressure Correction Factor
081 Mag List 2 Item 7 # 043 Total Correction Factor
082 Mag List 2 Item 8 # 048 Battery Voltage
083 Mag List 2 Item 9 # 031 Case Temperature
084 Mag List 2 Item 10# 203 Time
085 Mag List 2 Item 11# 204 Date
086 Mag List 2 Item 12# 255 (End-Of-List)
Example #3:
Suppose Display Test, Site ID, Corrected Volume, Uncorrected Volume, Live Gas Pressure, Live Gas
Temperature,
Gas Pressure Maximum, Unsquared Super, Battery Voltage and Case Temperature are the
only items desired for the meter reader list. The item code numbers listed below would be configured
as follows:
Item Item Legend Selected Description
Code# Item
075 Mag List 2 Item 1 # 009 Gas Pressure Maximum
076 Mag List 2 Item 2 # 047 Unsquared Super
077 Mag List 2 Item 3 # 048 Battery Voltage
078 Mag List 2 Item 4 # 031 Case Temperature
079 Mag List 2 Item 5 # 255 (End-Of-List)
080 Mag List 2 Item 6 # 255 (End-Of-List)
081 Mag List 2 Item 7 # 255 (End-Of-List)
082 Mag List 2 Item 8 # 255 (End-Of-List)
083 Mag List 2 Item 9 # 255 (End-Of-List)
084 Mag List 2 Item 10# 255 (End-Of-List)
085 Mag List 2 Item 11# 255 (End-Of-List)
086 Mag List 2 Item 12
# 255 (End-Of-List)
129 Live Display Enable Live PCor&T Live PCor Pressure & Temperature
130 Mag List 1 Item 1 # 061 Display Test
131 Mag List 1 Item 2 # 200 Site ID
132 Mag List 1 Item 3 # 000 Corrected Volume
133 Mag List 1 Item 4 # 002 Uncorrected Volume
134 Mag List 1 Item 5 # 255 (End-Of-List)
135 Mag List 1 Item 6 # 255 (End-Of-List)
Note:
Remember that all Mag List 1 and Mag List 2 items have a 1-minute time-out. Both live parameters have
a 10-minute time-out.
