Detector Sensitivity Settings Intelligent Sensing Applications
Ion
SMOKE (ION)
(See notes * , ** , and
†
)
AL:1=0.50 %
AL:2=0.75 %
AL:3=1.00 %
AL:4=1.25 %
AL:5=1.50 %
AL:6=1.75 %
~
AL:7=2.00 %
AL:8=2.25 %
AL:9=2.50 %
PA:1=Auto 
PA:2=0.40 %
PA:3=0.50 %
PA:4=0.75 %
PA:5=1.00 %
PA:6=1.25 %
~
PA:7=1.50 %
PA:8=1.75 %
PA:9=2.00 %
FlashScan Laser
‡
(See Note
**
)
AL:1=0.02 %
AL:2=0.03 %
AL:3=0.05 %
AL:4=0.10 %
AL:5=0.20 %
AL:6=0.50 %
~
AL:7=1.00 %
AL:8=1.50 %
AL:9=2.00 %
PA:1=Auto
PA:2=0.02 %
PA:3=0.05 %
PA:4=0.10 %
PA:5=0.20 %
PA:6=0.50 %
~
PA:7=0.70 %
PA:8=1.00 %
PA:9=1.50 %
Acclimate
Multi-Sensor
See Note
††
)
AL:1=0.50 %
AL:2=1.00 %
AL:3=1.00 to 2.00 %
AL:4=2.00 %
AL:5=2.00 to 3.00 %
~
AL:6=3.00 %
AL:7=3.00 to 4.00 %
AL:8=4.00 %
AL:9=thermal 135
o
F
Alarm (CLIP)
AL:1=1.00 %
AL:2=1.00 %
AL:3=1.00 to 2.00 %
AL:4=2.00 %
AL:5=2.00 to 4.00 %
~
AL:6=2.00 to 4.00 %
AL:7=2.00 to 4.00 %
AL:8=4.00 %
AL:9=4.00 %
PA:1=0.50 %
PA:2=1.00 %
PA:3=1.00 %
PA:4=1.00 to 2.00 %
PA:5=1.00 to 2.00 %
~
PA:6=2.00 %
PA:7=2.00 %
PA:8=2.00 to 3.00 %
PA:9=2.00 to 3.00 %
Heat (Adjustable Threshold) AL:1=43
°
C
AL:2=57
°
C
AL:3=63
°
C
~
AL:4=68
°
C
AL:5=74
°
C
AL:6=88
°
C
AL:7=88
°
C
AL:8=88
°
C
AL:9=88
°
C
PA:1=40
°
C
PA:2=43
°
C
PA:3=57
°
C
~
PA:4=65
°
C
PA:5=70
°
C
PA:6=75
°
C
PA:7=75
°
C
PA:8=75
°
C
PA:9=75
°
C
Beam
(See Note
‡‡
)
AL:1=25%
AL:2=30%
AL:3=40%
AL:4=50%
AL:5=30 - 50%
AL:6=40 - 50%
PA:1=50%
PA:2=55%
PA:3=60%
PA:4=65%
PA:5=70%
PA:6=75%
PA:7=80%
PA:8=85%
PA:9=90%
Intelliquad FSC-851
(See Note
***
)
AL:1= 1%
AL:2= 2%
AL:3= 3%
AL:4= 3% w/ 10 minute
confirmation period
****
AL:5= 4% w/ 10 minute
confirmation period

AL:6= Thermal 135°F
PA:1= 1%
PA:2= 2%
PA:3= 3%
PA:4= 3% w/ 10 minute
confirmation period
PA:5= 4% w/ 10 minute
conf
irmation period
PA:6= Thermal 135°F
Photo/CO
AL:1=1%
AL:2=2%
AL:3=3%
AL:4=3% with a 10 minute
confirmation period
****
AL:5=4% with a 10 minute
confirmation period
AL:6=Thermal 135°F
PA:1=1%
PA:2=2%
PA:3=3%
PA:4=3% with a 10 minute
confirmation period
PA:5=4% with a 10 minute
confirmation period
PA:6=Thermal 135°F
~
Signifies the factory default setting.
Detector Type Alarm (FlashScan) Pre-Alarm
Table D.2 Detector Sensitivity Settings (2 of 2)
