NFS2-3030 Programming Manual — P/N 52545:K1 03/20/2012 35
Panel Program Program
• Prioritized Audio Matrix (PAM) speaker points, in the format NxxxIyyyyAzzSn. xxx = the
DVC node number, yyyy = the input number in the PAM, zz = the DAA address on the
Digital Audio Loop (01 through 32), and n = the DAA speaker circuit (1 through 4).
Soft Keys
All soft keys function like they do on the ACS Point Programming Screen.
3.2.9 Supervision
From the Panel Program Menu (1), select SUPERVISION to display the following screen.
Figure 3.20 Supervision Screen
Soft Keys
MAIN POWER SUPPLY AC FAIL ADDRESS: Press to enter the “Monitor AC Fail” (base plus one)
address of the main power supply. Refer to the main power supply manual for complete addressing
information. Enter the power supply address and press ACCEPT.
The LCD backlight will turn off when this power supply experiences AC failure (see BACK
LIGHT
in Section 3.2.7, “LCD Programming”, on page 28).
PRINTER: Press to scrol
l through the types of printer supervision: NONE, 40-COLUMN,
40-COLUMN SUPERVISED, 80-COLUMN, 80-COLUMN SUPERVISED, 40 GRAPHIC, 80
GRAPHIC, 80 GRAPHIC SUPERVISED. The printer will not be active if NONE is selected. If a
SUPERVISED selection is made, the printer will be supervised. Default: NONE
CAUTION: DO NOT MIX GENERAL ZONES WITH OTHER SOURCE TYPES FOR AN ACS
CONTROL POINT. PROGRAM UP TO EIGHT GENERAL ZONES OR UP TO EIGHT OTHER
CONTROL POINT TYPES.
SUPERVISION
MAIN PS AC FAIL ADDRESS: LXXMXXX
PRINTER: 80-COLUMN
CRT BAUD RATE: 57600 MORE
AUXILIARY TROUBLE REPORTING:NO ACCEPT
TAMPER INPUT: NO BACK
NOTE: When changing from an 80-column or 80-column supervised to an 80 graphic or 80
graphic supervised printer (or vice-versa), settings must be changed at the printer. Refer to this
panel’s installation manual for the settings.
