NFS2-3030 Programming Manual — P/N 52545:K1 03/20/2012 89
Bootloader Screen Service Screens
DOWNLOAD TYPE: Press this soft key to scroll through the languages (LANGUAGE-ENGLISH,
LANGUAGE-HEBREW, LANGUAGE-PORTUGUESE, LANGUAGE-SPANISH), BANNER, APP
and BOOT. Stop at the desired selection.
Choose a language to change LCD-160s selected at the ADDR
ESS field to display in that
language.
Choose BANNER to add the panel banner to those LCD-160 displays selected at the AD
DRESS
field.
Select APP to
download an application file to the selected LCD-160(s).
Select BOOT to do
wnload a boot file to the selected LCD-160(s).
AUTO:Press this
soft key to automatically download to the LCD-160 the most up-to-date language,
bootloader, and application from the panel.
START:Press this
soft key to begin the download.
5.3.2 Loop Download Menu
This screen allows the programmer to select loops for downloading applications and/or boot
programming.
Figure 5.7 Loop Download Menu Screen
LOOP AD
DRESS: Press this soft key to scroll through the Loops. Stop at the appropriate pair, or
select ALL.
D
OWNLOAD TYPE:
Press this soft key to scroll through the download types. Stop at the
appropriate type. Selections are: APP, BOOT, or APP/BOOT.
Select APP to
download an application file to the selected loops.
Select BOOT to do
wnload a boot file to the selected loops.
Select APP/BOOT to select both for downloading.
A
UTO:Press this soft key to automatically download to the
selected loop(s) the most up-to-date
applications or boot programming from the panel.
START:Press this
soft key to begin the download.
TROUBLE
LOADING..NO SERVICE
LAKEVIEW GENERAL HOSPITAL
BOOTLOADER
LOOP DOWNLOAD MENU
11:58:45A TUE JAN 25, 2011
AUTO
LOOP ADDRESS: LOOPS 1+2 START
DOWNLOAD TYPE: APP BACK
