140 NFS2-3030 Programming Manual — P/N 52545:K1 03/20/2012
Type Codes Type Codes for Input Devices
PULL STATION fire alarm Y Y Manual fire-alarm-activating device
SMOKE CONVEN fire alarm Y Y Indicates activation of a conventional smoke detector. An FZM-1
must be used for alarm verification of a two-wire conventional
detector.
SMOKE DETECT fire alarm Y Y Indicates activation of a conventional smoke detector. An FZM-1
must be used for alarm verification of a two-wire conventional
detector
WATERFLOW fire alarm Y Y Monitor for waterflow alarm switch
WATERFLOW S supervisory Y Y Indicates supervisory condition for activated waterflow switch
ACCESS MONTR non-alarm
security
N Y Used for monitoring building access
AREA MONITOR security Y Y Monitors building access
AUDIO SYSTEM trouble N N Used for monitoring audio equipment (use trouble zones for
activations)
EQUIP MONITR non-alarm
security
N Y Used for monitoring equipment
FMM-420 user-
programmable
Y Y Monitors 4-20 mA industrial sensors.
SECURITY L security Y Y Indicates activation of security alarm
LATCH SUPERV supervisory Y Y Indicates latching supervisory condition
NC SUP L supervisory Y Y Indicates latching supervisory condition, where an open
circuit=active.
TRACK SUPERV supervisory N Y Monitors for waterflow tamper switches for alarm points
NC SUP T supervisory N Y Indicates tracking supervisory condition, where an open
circuit=active.
SPRINKLR SYS supervisory Y Y Monitors a waterflow device
SYS MONITOR security Y Y Monitors equipment security
TAMPER supervisory Y Y Indicates activation of tamper switch
ACK SWITCH non-alarm N N Performs Acknowledge function
ALLCALL PAGE non-alarm N Y Performs function AMG-1 All-call and telephone page
DRILL SWITCH
non-alarm
*
Y N Performs Drill function
EVACUATE SWITCH non-alarm* Y N Performs Drill function, activates silenceable fire outputs
FIRE CONTROL non-alarm N Y Monitors non-fire activations
NON FIRE non-alarm N Y Monitors non-fire activations
NC NON FIRE non-alarm N Y Monitors non-fire activations, where an open circuit=active.
PAS INHIBIT non-alarm N N Inhibits Positive Alarm Sequence
POWER MONITR trouble
†
N N Monitors main and auxiliary power supplies (use trouble zones for
activations)
RESET SWITCH non-alarm N N Performs Reset function
SIL SWITCH non alarm N N Performs Signal Silence function
TELE PAGE non-alarm N Y Performs function of page button on FFT-7. Allows remote paging
to a fire area
DISABLE MON disable N N When this point activates it will create a disable on the panel for that
poin
t. No CBE generated. Modules can not be disabled via ACS,
Alter Status, or over the network.
TROUBLE MON trouble N N Monitors trouble inputs (use trouble zones for activations)
Blank fire alarm Y Y Monitors for a device with no description
HEAT DETECT fire alarm Y Y Monitors for conventional heat detector
RF MON MODUL fire alarm Y Y Wireless alarm-monitoring device
RF PULL STA fire alarm Y Y Wireless manual fire-alarm-activating device
RF SUPERVSRY supervisory N Y Wireless supervisory-monitoring device
ABORT SWITCH non-alarm N Y Provides an abort function through a monitor module (connected to
a UL-listed abort station) for a releasing zone.
MAN RELEASE fire alarm
‡
Y Y Provides a manual release through a monitor module (connected to
a UL-listed pull station) for a releasing zone
MAN REL DELAY fire alarm† Y Y Provides a manual release with a 10-second delay through a
monitor module (connected to a UL-listed pull station) for a
releasing zone
SECOND SHOT fire alarm† Y Y Provides a second manual release through a monitor module
(connected to a UL-listed pull station) for a releasing zone
HAZARD ALRT non-fire N Y Monitors for a hazard alert
WEATHER ALRT non-fire N Y Monitors for a weather alert
PROCESS MON critical process Y Y Monitors for a critical process
Type Code Point Type
Point Characteristics
Latching
(Y=yes
N=no)
Activates
CBE
Device Function
Table G.2 Type Codes for Monitor Modules (2 of 3)
