Honeywell NOTIFIER AM-8000 - DEFINITIONS; LINE; POINTS; ZONES

AM_8000 Programming Manual PAGINA - 1
AM8000_manu-prog-ENG Doc. M-160.2-AM-8000-ENG Rev A1 NOTIFIER ITALIA
Do not try to use the control unit and devices connected without reading this manual
DETECTION SYSTEM LIMITS
An alarm or fire detection system can be very useful for the prompt warning of any dangerous
event
such as fire. In some cases it can automatically manage events (transmission of messages
for room evacuation, automatic fire-extinguishing, TVCC system interface, access route or
door blockage, automatic warning to authorities, etc.), but in any case, it does not ensure
protection against damages to propriety).
Moreover, each system may not properly operate if it is not installed and maintained
according to the manufacturer’s instructions.
 It is assumed that the user of this manual has performed a training
course and that he knows the applicable rules in force.
 The system and all its components must be installed in an
environment having the following features:
 Temperature: -5 °C ¸ +40 °C.
 Humidity: 10 % - 93 % (without condensation).
 Peripheral devices (sensors, etc.) which are not perfectly compatible
with the control unit may cause damages to the same control unit,
and a bad operation of the system in any moment. Therefore, it is
essential to only use material which is guaranteed by NOTIFIER and
is compatible with its own control units.
 Please consult NOTIFIER Technical Service for an
y
doubt.
.
