NCD Instruction Manual — P/N LS10210-051NF-E:C 2/18/2019 19
Board Layout and Wiring Requirements Installation
Piezo Enable/Disable
To enable the Piezo, position SW16 in the UP position.
To disable the Piezo, position SW16 in the DOWN posi-
tion.
When the Piezo is disabled the NCD will display a trou-
ble condition until it is re-enabled. See Figure 2.9
Figure 2.9 Piezo Enable/Disable
Piezo Enable/Disable
SW16
Core Board
DIM
Board
