SFP-5UD & SFP-10UD Series Manual— P/N 52879:C2 1/24/2012 15
Specifications Product Description
Alarm Silence
System Reset/Lamp Test
Drill
• LED Indicators
Fire Alarm
Supervisory
Trouble
AC Power
Alarm Silence
Primary and Secondary Phone Line Active LEDs
• Piezo sounder for alarm, trouble and supervisory
• 24 volt operation
• Low AC voltage sense
• Alarm Verification
• NACs Programmable for:
Silence Inhibit
Auto-Silence
Strobe Synchronization (System Sensor, Wheelock, Gentex, Faraday, Amseco)
Selective Silence (horn-strobe mute)
Temporal or Steady Signal
Silenceable or Nonsilenceable
• Automatic battery charger with charger supervision
• Silent or audible walktest capabilities
• Optional PS-Tools utilityfor local or remote Upload/Download of program and data
• Optional N-CAC-5X Class A Converter Module for NACs and IDCs
• Optional 4XTM Transmitter Module
• Optional ANN-SEC card for a secondary ANN-BUS
1.2 Specifications
AC Power
SFP-5UD (FLPS-3 Power Supply): 120 VAC, 60 HZ, 1.00 amps
SFP-5UDC (FLPS-7 Power Supply): 120 VAC, 60 HZ, 3.90 amps
SFP-10UD(C) (FLPS-7 Power Supply): 120 VAC, 60 HZ, 3.90 amps
SFP-5UDE (FLPS-3 Power Supply): 240 VAC, 50 HZ, 0.54 amps
SFP-10UDE (FLPS-7 Power Supply): 240 VAC, 50 HZ, 2.20 amps
Wire size: minimum #14 AWG (2.0 mm
2
) with 600V insulation
Supervised, nonpower-limited
Battery (sealed lead acid only) - J12
Maximum Charging Circuit - Normal Flat Charge: 27.6 VDC @ 1.4 amp
Supervised, nonpower-limited
Maximum Charger Capacity: 18 Amp Hour battery for SFP-5UD, and 26 Amp Hour battery for
SFP-5UDC and SFP-10UD(C)/E [two 18 Amp Hour batteries can be housed in FACP cabinet.
Larger batteries require a separate battery box such as the NFS-LBB or BB-26 and the CHG-75 or
CHG-120 Battery Charger.]
Minimum Battery Size: 7 Amp Hour (12 Amp Hour for SFP-5UD-7C & SFP-10UD-7C)
NOTE: For wiring specifications, refer to“Wire Requirements” on page 153.
