OMNI-408/OMNI-408EU Installation and Setup Guide
7–4
NOTE: The checkmarks highlight which options are selected.
FORMAT PULSE SPEED
HANDSHAKE
FREQUENCY
Digit
10 PPS 20 PPS 40 PPS 1400 HZ 2300 HZ
PARITY TYPICAL CS RECEIVER
0
9
9
FBII, ADEMCO, SILENT KNIGHT
1
9
9
FBII
2
9 9
FBII
4
9
9
FBII, SILENT KNIGHT, ADCOR, ADEMCO
5
9
9
FBII
6
9
9
FBII, RADIONICS
8
9
9
9
FBII, FRANKLIN, SESCOA, DCI, VARITECH
9
9
9
9
FBII, RADIONICS
A
9 9
9
FBII
C
9
9 9
FBII
D
9
9 9
FBII
E
9
9 9
FBII, RADIONICS
NOTE: UL-compatible receivers are: FBII CP220 (all formats), ADEMCO 685, Silent Knight 8520,
9000, RADIONICS.
Question 06, L3
AC Line Frequency, Split Reporting, & Pulse Type OMNI-408 Default = 1
OMNI-408EU Default = 3
Enter the digit for the desired message length from the table below in Location L3.
NOTE: The checkmarks highlight which options are selected.
AC LINE FREQUENCY DIALING TYPE
Digit
50 HZ 60 HZ
SPLIT
REPORTING
PULSE Touchtone
0
9
9
1
9
9
2
9
9
3
9
9
Please consult your central
station manager to
determine the formats and
message lengths that are
accepted by the receiver.
4
9
CS DIALER DISABLE
6
9
CS DIALER DISABLE
8
9 9 9
9
9 9
9
A
9
9 9
B
9
9
9
U
L
European dialing format has
not been tested by UL.
The CS dialer disable
selection shall not be
selected for UL installations.
SPLIT REPORTING - The Split Reporting option directs all opening and closing signals to the
secondary receiver telephone number. All other conditions (alarms, troubles, restores, etc.) adhere to
the reporting route described in Question 01. If Split Reporting is selected, the secondary receiver
telephone number MUST be programmed.
If Local Alarm is desired, no other options need to be disabled (telephone number, CS
codes).
