OMNI-408/OMNI-408EU Installation and Setup Guide
8–2
Question 13 RF Keyfob 5 Serial Number
CS User Number 12 Function Q34 Default = 000000000
Select the options for Keyfob 5 in L1 - L9. Enter the valid digits from the tables below.
Question 14 RF Keyfob 6 Serial Number CS User Number 13 Function Q35 Default = 000000000
Select the options for Keyfob 6 in L1 - L9. Enter the valid digits from the following tables.
Questions 01-10, L1 - RF Device Options
Digit OPTION EXPLANATION
0 Disabled Not applicable
1 1 Zone or Button Only 1 Zone or 1 Button
2 2 Zones or Buttons 2 Consecutive Zones or 2 Buttons
3 3 Zones or Buttons 3 Consecutive Zones or 3 Buttons
4 4 Buttons 4 Buttons (Keyfobs)
NOTE: Any zones programmed in RF Programming must also be enabled in Question 26.
Questions 01-10, L2 - RF Device Type
Digit TYPE EXPLANATION
0 Disabled Not applicable
1 5800 Transmitter 5800 Series Transmitters (select for keyfobs)
9 5816 Transmitter 5816 Transmitter using magnetic relay only
Questions 01-10, L3 through L9 - 5800 Serial Number
For all 5800 RF devices to be used, enter the 7-digit serial number printed on the device.
If an RF device is not to be used, program a “00” into the locations corresponding to the device.
NOTE: When programming a device that uses multiple zones, you must skip the additional zones
supported by that device by disabling them. For example, if zone 2 has a device that has been
programmed to support three zones, the next two zones must be disabled, and the following zone must
be zone 5.
To disable an RF point that has been previously programmed, you must:
1. Remove the RF enable for the appropriate zone in Question 26; and
2. Make the first 2 digits in the RF programming for that zone “00.”
Example of RF Programming
In this example of RF Programming, assume that a four-button keyfob is being enabled as keyfob
number 1, the keyfob has a serial number of “A 123 4567," and that only one question (09) is being
programmed at this time.
