Model SK-5208 Fire Control/Communicator Installation and Operation Manual
4-6 P/N 151204
4.2.3 NAC Cadence
Figure 4-5 illustrates, in more detail, the programming flow when in the NAC cadence menu.
Figure 4-5 NAC Cadence
4.2.3.1 Cadence Patterns
The cadence patterns shown in Table 4-2 can be selected for NAC outputs. Each NAC can
select an output pattern. Special cadence patterns can be selected for fire drill or an auxiliary
input switches used with the system.
Table 4-2: Cadence Patterns
#Name
Pattern Description
(Patterns repeat until condition is cleared)
1 Constant Output Continuous sound
2 March Code Output
3 ANSI S-3.41 Code Output
4 Single Stroke BI
5 California Code
6 System Sensor Sync. Provides Synchronization for visual and audible devices.
7 Wheelock Sync.
8 Gentex Sync.
9 Faraday Sync.
10 Amseco Sync.
