Honeywell ST 3000 Installation Guide

A.6 Configuring Smart Meter Using SFC, Continued
Procedure, continued
Table A-9 Setting Up Smart Meter Configuration Using an SFC, continued
Step Press Key Read Display or Action Description
3
ENTER
(YES)
NON-VOL
SCFO
W
RK NI.G..
CMe ntr oef
ig
Perts
en
Me t re
CMe ntr oef
ig
Bd
Enters meter configuration function
and confirms that smart meter is
present. Timed prompt - Proceed to
Step 4.
ATTENTION
If prompt “No Meter
Present” appears, prompt times out
in a few seconds, as described
above, and calls up the Configure
Meter? prompt. This means that
you can access the meter
configuration function without the
smart meter installed. Proceed to
Step 4. If prompt “Mtr not Supportd”
appears, prompt times out and
returns to previous ST CONFIG
prompt (See Step 2.). This means
that you are working with a pre-
release 300 transmitter that does
not support the smart meter option
and, therefore, can not access the
meter configuration function.
4
Cnouf
ig
Me t re
CMe ntr oef
ig
re ?
Prompt asks if you want to configure
Smart Meter. If you want to
configure it, go to Step 5. If you do
not want to configure it, press [
CLR]
key to exit function.
Continued on next page
2/05 ST 3000 Release 300 Installation Guide
75
