Unpacking
3. Unpacking
The fire alarm control panels are simple to install, program, and commission if you follow
the recommended procedures described in this guide.
Before installing the panel, ensure that all the equipment is received as per the table given
below.
The packing box should contain the following items as provided in the table below:
ITE
M
COMPONENT
UL
SKU
NO.

615-000-002,
615-000-002-R
615-000-102,
615-000-102-R,
615-000-202,
615-000-202-R
915-100-102,
915-100-102-
R, 915-100-
202, 915-100-
202-R, 915-
100-402, 915-
100-402-R
QUANTITY
1 FIRE ALARM CONTROL PANEL 1 1 1
2 QUICK START GUIDE 1 1 1
3 INSTALLATION KIT ACCESSORIES 1 1 1
3.1 PLUG-IN TERMINAL BLOCK (2 PIN)
- GREEN
4 4 7
3.2 PLUG-IN TERMINAL BLOCK (3 PIN)
- GREEN
2 2 4
3.3 PLUG-IN TERMINAL BLOCK (4 PIN)
- GREEN
2 3 5
3.4 PLUG-IN TERMINAL BLOCK (5 PIN)
- GREEN
1 1 1
3.5 ASSEMBLY, END-OF-LINE DEVICE,
4.7K
4 4 4
3.6 ASSEMBLY, END-OF-LINE DEVICE,
10K
1 1 2
3.7 CABLE HARNESS - BATTERY LINK
CONNECTIONS
1 1 1
