27
Commissioning
Figure 5.19 Edit User Passcode
NOTE: Enable Show Passcode option to view the passcode you are entering.
5.4 Configuration via Bluetooth
This feature enables you to configure the panel via Bluetooth. You can send and receive
configuration file via Bluetooth between panel and PC tool/Mobile App.
5.4.1 Transferring the Configuration File
To transfer the configuration file from the mobile to the panel, follow the steps given below:
1. Connect the Bluetooth Dongle to the USB port in the panel and tap OK.
Figure 5.20 Bluetooth Detected
2. In the Commissioning screen, tap next to Configuration via Bluetooth option.
ReferFigure 5.2 on page 16.
3. On the mobile, switch-on the Bluetooth and discover the HONBLEKIT2 connection.
4. Enter the passcode that is appearing in the panel in your mobile device.
