Commissioning
5.6 Event Log Explorer
An event log registry can store a maximum of 10000 events. You can transfer the event logs
to the USB.
1. In the Commissioning screen, tap next to the Event Log Explorer. Refer Figure 5.2
on page 16. The Event Log Explorer screen opens with the SEND TO USB option in the
enabled mode.
2. Tap SEND TO USB. The log file will be sent to the USB.
Figure 5.24 Sending the Configuration File
NOTE: If the USB dongle is not connected the SEND TO USB options is disabled.
3. Wait for the confirmatory message for the files to be sent. Tap OK to close the message.
NOTE: The .ele file can be used with the PC tool /mobile app to view the details of the event log.
2 The selected config file has loop
mismatch with this panel variant.
The number of loops of the source panel and the target
panel are different. For example, the number of loops in
the configuration file is 2. However, the number of loops
in the target panel is 4.
Corrective Action:
Use a configuration file of a panel with same number of
loops.
3 The selected config file is corrupted.
Please try again.
The configuration file in use is corrupted.
Corrective Action:
Use a configuration file, which is not corrupted.
Table 5.1 USB-Related Error Messages
Serial
No.
Error Message Details
