29
Commissioning
5.4.2 Sending the Configuration File
To send the configuration from the panel to the mobile, follow the steps below:
1. For inserting the dongle and paring the mobile device, following “steps 1 to 6” from
Transferring the Configuration File on page 27.
2. Send a configuration file from the panel to the mobile device or the desktop tool.
3. A confirmation message is shown once the configuration file is sent successfully.
4. After successful transfer of the configuration file, you can eject the bluetooth dongle.
5.5 Configuration via USB
You can export or import the configuration file. The Configuration screen has the following
options:
• READ FROM USB
• SEND TO USB
5.5.1 READ FROM USB
1. In the Commissioning screen, tap next to the Configuration via USB. Refer
Figure 5.2 on page 16.
NOTE: The READ FROM USB option is enabled only when you insert the USB dongle, which has the
configuration files to the ROOT directory.
2. Insert the USB storage device in the panel.
NOTE: The READ FROM USB and SEND TO USB buttons are enabled.
3. Tap READ FROM USB.
Figure 5.22 Configuration
4. Tap YES if you want to replace and tap NO to retain the current configurations.
5. The following screen appears if you tap YES.
