24
Commissioning
37. Tap next to the Sounder to configure the Programmable Zones.
Figure 5.14 Local Outputs
38. Tap EDIT PRG ZONES to edit the programmable zones. For more information on editing
a programmable zone, see Figure 5.12 on page 22.
NOTE: For Programmable Relay, by default the Switch to Supervisory is in YES mode. If you want to configure
the programmable zones then you need to set the option as NO and then tap EDIT PRG ZONES. If the option is
set to YES, then no further configuration is required.
39. Set Silence to either YES or NO. This parameter determines whether the output will turn
ON/OFF when the SILENCE / RESOUND key is pressed.
5.2 Learn
1. In the Commissioning screen, tap next to the LEARN tab. The following image lists
all the loops available in the panel along with learn peripheral option.
2. Tap
LEARN for a particular loop.
Figure 5.15 Learn Screen
