CONFIGURATION
Touchpoint Pro
Pt. No. 2400M2566_1_EN 26 Operating Manual
4.2 To Back Up the Configuration
1. Ensure that the destination drive is inserted in the Control Module.
2. Login as an Engineer.
3. From the System Status screen select the Tool Box icon then System Configuration
then System Management.
4. Re-enter the password and select Login.
5. Select CCB Management and click on Configuration Backup:
6. Select the required drive.
7. The system will display a message ‘The configuration backup process might take a few minutes. The User Interface
is not accessible during this time. Do you want to proceed?’ Ensure that destination drive is always connected during
this operation.
8. Once the action is confirmed, the configuration backup process starts and a progress message is displayed. The
backup may take several minutes depending on the system size.
9. The Configuration backup file is stored on the memory device in:
TPPR Configuration\TPPR_Config_SystemID_<sequence>.bin
e.g.: TPPR_Config_SYSTEMSPL0003_009.bin
4.3 Restoring the Configuration
Please refer to the Touchpoint Pro Technical Handbook.
4.4 Deleting the Configuration
The Administrator has the option to delete the system configuration. This option is for specific circumstances only, and is
not intended for normal use. See the Touchpoint Pro Technical Handbook for further information.
