15 Ordering Information
15.1 TPPR System ID Configuration
Your TPPR has a unique System ID that incorporates a Globally Unique Identifier (GUID). A typical example might be TPPR–HW–MF–NXHXXL–ZII8421526123, where the first 14
characters show the system's configuration and the last 13 characters are the GUID (see box-out below).
The System ID and GUID are produced in digital, human and barcode reader formats for ease of tracking and quality control. They can be found on both the TPPR rating plate and in the UI
software.
The following table shows how your TPPR System ID is constructed and this GUID can be used to provide valuable information to Technical Support if you need technical help or warranty
service.
System ID
Product
Name
Unit Type Variant* Ventilation Plinth Logo BIB CCB-R UI
See Example
below.
TPPR
HW = Wall
Mount
S = Small
M = Medium
L = Large
+
F = Front
Access
R= Rear
Access
X = None
X = None X = None X = None X = None
L = Local
(With UI)
N = Natural
HF = Floor
Standing
P = 100mm
H =
Honeywell
M = Modbus
R =
Redundancy
R = Remote
(Without UI)
F = Forced
Example: TPPR– HW– MF– N X H X X L
Table 19. TPPR Standard System ID Configuration Chart
S = Supplier Code i.e. Z for HA Poole UK
II = Bill of Materials Issue Number
PPP = Part Code i.e. 842 for a standard WM
Enclosure
YY =Year of Manufacture
WW = Week of Manufacture
NNN = Sequential Serial Number
FS = Front Access Floor Cabinet with 5 Backplanes
RS = Rear Access Floor Cabinet with 5 Backplanes
TS = Small Stainless Steel Wall Cabinet
Z = Zone 2 Div. 2 Stainless Steel Wall Cabinet
