FAAST FLEX Product Guide FAASTFLEX
7 www.xtralis.com
Specification Value
Flow Fault ± 20% of the reference flow (according to EN54-20)
IP Rating IP40
Mechanical
Exterior Dimensions 204 mm x 280 mm x 80.5 mm
Wiring 0.5 mm² to 2.5 mm² maximum
Pipe Network Layout Single Channel Model
l Linear pipe length: 1 X 105m (344 ft)
l Branched pipe length: 2 X 105m (344 ft) or 4 X 68m (223 ft)
Dual Channel Model
l Linear pipe length: 2 X 105m (344 ft)
l Branched pipe length: 4 X 105m (344 ft) or 8 X 49m (161 ft)
Note: Results can be achieved using CAD.
Maximum Number of
Holes
Refer to section "9 Piping Design Guidelines" for more information.
Pipe Spec
(EN54-20 Compliance)
EN 61386 (Crush 1, Impact 1, Temp 31)
Outside Pipe Diameter 27 mm (nom) or 25 mm (nom) with plug/adapter
Shipping Weight 1.7 kg (including sensors)
Table2-2: FAAST FLEX Detector Specifications (continued...)
