FAASTFLEX FAAST FLEX Product Guide
www.xtralis.com 43
DIAGTEST.TXT File Format
The DIAGTEST.TXT file will contain the result of the test in the format shown below.
1CH 2CH
SELF_TEST_RED_LIGHT_PASSED |
SELF_TEST_GRE_LIGHT_PASSED |
SELF_TEST_YEL_LIGHT_PASSED |
SELF_TEST_NORMALSTA_PASSED |
SELF_TEST_ACTIO_CH1_PASSED |
SELF_TEST_ALARM_CH1_PASSED |
SELF_TEST_FAULT_CH1_PASSED |
SELF_TEST_ACTIO_CH2_NOTAVA |
SELF_TEST_ALARM_CH2_NOTAVA |
SELF_TEST_FAULT_CH2_NOTAVA |
SELF_TEST_RED_LIGHT_PASSED |
SELF_TEST_GRE_LIGHT_PASSED |
SELF_TEST_YEL_LIGHT_PASSED |
SELF_TEST_NORMALSTA_PASSED |
SELF_TEST_ACTIO_CH1_PASSED |
SELF_TEST_ALARM_CH1_PASSED |
SELF_TEST_FAULT_CH1_PASSED |
SELF_TEST_ACTIO_CH2_PASSED |
SELF_TEST_ALARM_CH2_PASSED |
SELF_TEST_FAULT_CH2_PASSED |
6.4 PROTECTION Mode
The device goes in PROTECTION in the following situations:
l Dataflash fault
l Power supply overvoltage
In PROTECTION mode, the POWER LED is steady red. The device switches off all peripherals and
communications and reports fault by activating fault relays (the unit reports fault through relays only). The only
way to exit PROTECTION mode is to completely power off the device and then power it back up.
6.5 SERVICE (or STANDBY) Mode
If the cover is left open for more than 60 seconds the device enters SERVICE Mode and the POWER LED
blinks red (fast blink). This mode is typically used during hardware maintenance, for example changing or
cleaning a filter screen in the field. During this working mode (also referred to as STANDBY Mode), the device
switches off the aspirator, stops monitoring flows and sensing elements. No alarms will be shown on the
LEDs, relays (fault relays activated), or buzzer.
Additionally, USB and buttons sensing are turned off while Bluetooth is enabled to report SERVICE mode
only. From the SERVICE mode, users can initiate the password recovery process during the EEPROM
factory reset and aspirator spare part replacement.
6.5.1 Passcode Recovery
In the event the passcode has been lost, perfom the following steps to recover the passcode .
Action Button LED Display Description
Open cover and allow device
to enter SERVICE Mode (60
second wait).
LED 5 will fast blink red
when the device enters
SERVICE Mode.
Plug a formatted USB drive
into the port.
Long press the ENTER
button.
Long
Press
LED 5 will go out and
LEDs 1, 2, 3, and 4 will
flash yellow, and the
buzzer will sound to
indicate that the reset file
has been written to the
USB drive.
Email the file from the USB drive to your device supplier. The passcode will be recovered by Xtralis
Customer Support and will be communicated by the vendor back to you via email or telephone.
