Action Button Action(s) Description
Press the TEST
button to confirm test
PASS or press
Silence to enter test
FAIL.
Short
Press
1 3
2
4
5
6
LED 4 shows red and
LED5 shows green to
indicate Action
condition on Channel
2. (Test step must be
completed even on
Single Channel units).
Relay activation can
be checked, however
in case of single
channel unit the relay
is not available.
Press the TEST
button to confirm test
PASS or press
Silence to enter test
FAIL.
Short
Press
1 3
2
4
5
6
LED 3 shows red and
LED5 shows green to
indicate Alarm
condition on Channel
2. (Test step must be
completed even on
Single Channel units).
Relay activation can
be checked.
Press the TEST
button to confirm test
PASS or press
Silence to enter test
FAIL.
Short
Press
1 3
2
4
5
6
LED 5 shows green
and LED 6 shows
yellow to indicate Fault
condition on Channel
2. (Test step must be
completed even on
Single Channel units.)
Press the TEST
button to confirm test
PASS or press
Silence to enter test
FAIL.
Short
Press
1 3
2 4
5
6
1 3
2
4
5
6
LED 6 shows green if
all tests PASS.
LED 6 shows yellow if
any step FAILs.
Press the RESET
button to exit TEST
mode or Insert a USB
drive and press the
ENTER button to
download test results.
Short
Press
Short
Press
The results of the test
will be written to the
USB drive in the file
DIAGTEST.txt and the
device will beep to
provide an audible
confirmation that the
process is complete.
