Honeywell Xtralis FAAST FLEX FLX-020 User Manual

FAAST FLEX Product Guide FAASTFLEX
49 www.xtralis.com
Single Channel:
Pipe Length with low aspirator speed
with high aspirator speed
Exhaust
First hole position
Last hole position
Step between holes
Hole position deviation from nominal position
45° or 90° Bend corresponds to a straight pipe length of
T junction corresponds to a straight pipe length of
Clips distance
TT
max 1.5m
F
S
30m - E
min 1m
0.3m
1.2m
max 90s
S ± 20%
L / (Number of holes-1)
min 2.5m
Rules
E
max 29m
L
PL - E - F
PL
max
50m
max 80m
Figure9-1: Piping Design Parameters - I Pipe
