FAAST FLEX Product Guide FAASTFLEX
51 www.xtralis.com
Dual Channel:
Pipe Length with low aspirator speed
with high aspirator speed
Exhaust
First hole position, Chamber 1
Step between holes
Hole position deviation from nominal position
45° or 90° Bend corresponds to a straight pipe length of
Clips distance
TT
max 1.5m
F
S1, S2
max (see table row A) -E
min 1m
0.3m
max 90s
Sx ± 20%
Lx / (Number of branch holes-1)
Rules
E
see table row B
max
50m
max 80m
PL
T junction corresponds to a straight pipe length of 1.2m on the
common branch
La
st hole position, Chamber 1 L1
La
st hole position, Chamber 2 L2 L1-10%÷L1
First hole position, Chamber 2
F2 F ± 20%*S2
PL - T - F
Figure9-3: Piping Design Parameters - I Pipe
